Linear Led Module 2 feet 560x20mm 18V LINNEA

Linear Led Module 2 feet 560x20mm 18V LINNEA

DK250917_MOD-36R560x20 36V_18Vper1FT_VA01([No Variations])_3D.JPG

LINNEA 18V LED module with a length of 560 mm and width of 20 mm for linear lighting systems. Ensures even light distribution, energy efficiency, and stable performance.

Max efficiency [lm/W]	204 lm/W
Voltage [Vf]	36 V
Length [mm]	560 mm
Width [mm]	20 mm
Color temp [K]	2700-6500K
CRI/RA	80/90
PCB Material	FR4

Files to download

Datasheet-general

General terms and conditions of guarantee.pdf

DK250917_VA01_3D.step

Variants Linear Led Module 2 feet 560x20mm 18V LINNEA (14)


MOD-36R560x20-JB2835BJ-5090-VA01	1000 lm	5000 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-6590-VA01	1000 lm	6500 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-2790-VA01	894 lm	2700 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-4090-VA01	1000 lm	4000 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-5790-VA01	1000 lm	5700 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-3590-VA01	966 lm	3500 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-6580-VA01	1169 lm	6500 K	80	36 V	55 °C
MOD-36R560x20-JB2835BJ-3090-VA01	935 lm	3000 K	90	36 V	55 °C
MOD-36R560x20-JB2835BJ-4080-VA01	1169 lm	4000 K	80	36 V	55 °C
MOD-36R560x20-JB2835BJ-5780-VA01	1169 lm	5700 K	80	36 V	55 °C
MOD-36R560x20-JB2835BJ-3580-VA01	1135 lm	3500 K	80	36 V	55 °C
MOD-36R560x20-JB2835BJ-3080-VA01	1098 lm	3000 K	80	36 V	55 °C

14 Variants

Linear Led Module 2 feet 560x20mm 18V LINNEA
