Linear Led Module 2,5 feet 1400x24mm 12V LINNEA

Linear Led Module 2,5 feet 1400x24mm 12V LINNEA

DK250923_MOD-160R1400x24 60V(12Vper1FT)_VA01_3D.JPG

LINNEA 12V LED module with a length of 1400 mm and width of 24 mm for large-scale lighting systems. Features high efficiency and even light distribution.

Max efficiency [lm/W]	201 lm/W
Voltage [Vf]	60 V
Length [mm]	1400 mm
Width [mm]	24 mm
Color temp [K]	2700-6500K
CRI/RA	80/90
PCB Material	FR4

Files to download

Datasheet-general

General terms and conditions of guarantee.pdf

DK250923_VA01_3D.step

Variants Linear Led Module 2,5 feet 1400x24mm 12V LINNEA (14)


MOD-160R1400x24-JB2835BJ-6580-VA01	6035 lm	6500 K	80	60 V	55 °C
MOD-160R1400x24-JB2835BJ-4090-VA01	5155 lm	4000 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-2780-VA01	5450 lm	2700 K	80	60 V	55 °C
MOD-160R1400x24-JB2835BJ-2790-VA01	4610 lm	2700 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-6590-VA01	5155 lm	6500 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-5780-VA01	6035 lm	5700 K	80	60 V	55 °C
MOD-160R1400x24-JB2835BJ-5090-VA01	5155 lm	5000 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-3090-VA01	4825 lm	3000 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-3590-VA01	4980 lm	3500 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-5790-VA01	5155 lm	5700 K	90	60 V	55 °C
MOD-160R1400x24-JB2835BJ-5080-VA01	6035 lm	5000 K	80	60 V	55 °C
MOD-160R1400x24-JB2835BJ-4080-VA01	6035 lm	4000 K	80	60 V	55 °C

14 Variants
